Reconstructive Surgery & Anaplastology

We present a case report of a 59-year-old right hand dominant fork-lift truck driver who presented to the Regional Sarcoma Unit at the Leeds General Infirmary with a rapidly enlarging painless mass in his right upper arm. Initial ultrasound revealed a lobulated mass with significant internal vascularity. Subsequent MRI demonstrated a large 7.5 cm x 3.5 cm x 3 cm heterogenous mass within the anterior deltoid and bicep brachii muscles of the right arm that was abutting the anterior surface of the humerus (Figure 1). Imaging was suspicious for a malignant tumour. Staging Computer Tomography scan was negative for metastasis. An ultrasound guided biopsy confirmed a grade 3 leiomyosarcoma.

Figure 1: MRI of Leiomyosarcoma abutting humerus

He underwent a combined plastic and orthopedic surgery procedure involving tumour resection including lateral deltoid and half of bicep brachii muscles with preservation of the musculocutaneous nerve. He also had a 180-degree resection of humerus that was abutting the tumour. The orthopedic team performed simultaneous prophylactic intra-medullary nailing at the same time as tumour resection. Prophylactic intramedullary nailing of the humerus was performed at the same time as the resectional surgery so as to protect the weakened humerus from fracture, both in the early post-operative mobilisation period and also in the post-radiotherapy period. It enabled him to safely commence early active mobilisation with the sarcoma physiotherapists resulting in 100 degrees shoulder flexion and 90 degrees shoulder abduction at four weeks and fitness to return to work.

Histopathology revealed a grade 3 leiomyosarcoma that was completely excised. Recovery was uneventful and he began radiotherapy five weeks post-operatively (Figure 2).

Figure 2: Post Operative Radiographs showing excised bony window and humeral nail

Radiotherapy with limb-sparing surgery improves local control in high grade soft tissue sarcoma (STS) of the extremities [1]. Importantly, radiotherapy commenced within 3-6 weeks, once the surgical wound has healed has been shown to confer improved local recurrence rates and survival [2]. High-dose radiation is injurious to bone and is a known risk factor for the development of late fractures [3]. The incidence of femur fracture following STS resection and radiotherapy ranges from 5-9% [2,4-7]. Little data exists on the rate of pathological fractures in the upper limb. One study shows a similar rate of fracture between upper limb and lower limb sarcomas at 5 years [8]. Upper limb pathological are of particular concern due the heavy function disability this confers and the lack of suitable soft tissue coverage and risk of wound breakdown any subsequent fixation risks. Post-operative brachy therapy (BRT) gives the opportunity to offer small volumes of radiation over a shorter period of time. But whilst BRT has shown promising results in terms of lower recurrence, it has failed to demonstrate a reduced fracture risk in long bones with periosteal stripping [9]. Intensity Modulated Radiotherapy (IMRT) permits dose contouring to enable accurate targeting of tumor cells whilst minimizing dose to uninvolved tissues. A recent large prospective phase-II clinical trial demonstrated no difference in total wound complications as compared with EBRT but of interest it did show a 0% fracture rate in long bone STS [10]. As of yet, there have been no comparative studies of EBRT and IMRT; thus, the potential advantages of IMRT remain speculative.

But despite these advances in radiotherapy the role of prophylactic fixation of long bones has been previously advocated for lower limb STS [11]. We show a case where prophylactic intramedullary nailing of the humerus at the time of primary surgery was deemed appropriate because of the periosteal and cortical bone removed during resection, and also because it was the dominant arm of a heavy built manual laborer.

This case highlights the importance of managing these complex cases in a multidisciplinary setting. Having a single surgical event allowed expedient radiotherapy to be delivered, as no secondary procedure was required. We therefore suggest that all STS that may require periosteal stripping or segmental removal of bone, and subsequent radiotherapy be discussed at a regional multidisciplinary meeting to plan a combined plastic and orthopedic surgical procedure. This will provide the best outcome whilst simultaneously reducing the risk of pathological fracture. Dedicated upper limb physiotherapy is essential not only in the immediate postoperative stage to minimize morbidity but also during radiotherapy to reduce the risk of contractures and maintain range of movement. This combined multidisciplinary approach will ultimately ensure the best possible oncological and functional outcome for these complex cases.
